| 1/2.8” 5 Megapixel progressive scan STARVIS CMOS |
| H.265 & H.264 triple-stream encoding |
| 30fps@5MP (2592x1944) |
| TRUE - WDR |
| Face capture |
| Camera-Model | GS-PH351H2KA |
| Resolution | 5MP 2592(H)×1944(V) |
| Image Sensor | 1/2.8" Progressive CMOS |
| Min.Illumination | Color 0.01lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON |
| Shutter | 1/5 ~ 1/20000s |
| Slow shutter | Support |
| Lens | 2.8mm H.FOV: 77° |
| F No. | F No. 2.0±5% |
| Day & Night | IR cut filter with auto |
| Digital noise reduction | 3D DNR |
| WDR | 120 dB |
| Video Compression | H.265/H.264 |
| Video bit rate | 8Kbps ~ 8Mbps |
| Triple Stream | Yes |
| Resolution | Mainstream (1~ 30fps default 30fps) 5MP (2592x1944),4MP(2592x1520), 3MP (2304x1296)(2048x1535) 1080P (1920x1080), 720P(1280x720), Substeam (1~ 30fps default 10fps) 1080P(1920x1080),720P(1280x720), VGA(640x480),QVGA(320X240) Mobilestream (1~ 30fps default 10fps) VGA(640X480), QVGA (320X240) |
| Image Settings | Flip, Rotation, Corridor mode, Saturation, Brightness, Contrast, Hue, Sharpness adjustable |
| BLC | Support |
| ROI | Support |
| Privacy Mask | Support |
| Video Analytics | Perimeter Intrusion Detection, Line Crossing Detection, Sationary Object Detection, Pedestrian Detection, Face Detection (DEEP LEARNING), Cross Counting. |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, HTTPS, FTP, API, IPv4, IPv6 |
| System Compatibility | ONVIF (Profile S, Profile G) |
| Interface | RJ45 10M / 100M Ethernet interface x1 |
| Led | 18pcs(SMD) |
| IR Range | Up to 30m |
| PoE | Yes |
| Water Proof | IP 66 |
| Power Supply | DC 12V/POE |
| Consumption | ≤ 6W |
| Dimension | Ø69 X 138mm |
| Weight | appr. 320g |
| Storage Temperature | -30～+60°C |
| Operating Temperature | -30～+55°C |
